Description
The AQUAPHOR APRO 100 PRO is a professional, ultra-compact reverse osmosis (RO) water purification system designed to deliver high-quality treated water for commercial coffee machines, restaurants, hotels, cafés, offices and other HoReCa applications.
Featuring an advanced reverse osmosis membrane filtration system, integrated feed pump, digital monitoring controller and adjustable mineralisation bypass, the APRO 100 PRO combines professional water purification performance with a compact, portable design.
With a treated-water production capacity of up to 100 litres per hour, the system provides an efficient water treatment solution for businesses requiring consistent water quality while minimising limescale formation and protecting connected beverage equipment.
The advanced reverse osmosis membrane reduces dissolved salts, hardness minerals and a wide range of unwanted impurities, helping prevent scale buildup inside coffee machine boilers, valves, heating elements and internal water circuits.
Its innovative adjustable bypass remineralisation system allows users to blend a controlled proportion of incoming water with purified water, enabling adjustment of final mineral content to support coffee extraction, beverage taste and equipment protection.
Equipped with an integrated inline TDS monitoring system and electronic controller, the APRO 100 PRO enables operators to monitor water quality, system performance and prefiltration cartridge usage.
The system incorporates sediment and activated carbon prefiltration to reduce suspended particles, chlorine and other contaminants before water reaches the reverse osmosis membrane, helping protect its operation and service life.
Designed for convenient commercial installation, the compact Plug & Play configuration integrates the main filtration components, feed pump, membrane and electronic controls within a portable, coated metal enclosure.
Its energy-efficient design, high water recovery and convenient service access make the APRO 100 PRO suitable for professional beverage equipment installations and preventative maintenance programmes.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | AQUAPHOR |
| Product Name | APRO 100 PRO |
| Model / Product Code | 523008 |
| Product Range | AQUAPHOR Professional – APRO 100 Series |
| Product Category | Water Filtration Systems |
| Subcategory | Commercial Reverse Osmosis Systems |
| Equipment Type | Professional Reverse Osmosis Water Purification System |
| Filtration Technology | Reverse Osmosis with Sediment and Carbon Prefiltration |
| Water Treatment Process | Sediment Filtration, Carbon Filtration and RO Membrane Separation |
| Maximum Permeate Capacity | 100 Litres per Hour |
| Maximum Permeate Production | Approximately 1.67 Litres per Minute |
| Maximum Inlet TDS | 1,500 ppm |
| Reverse Osmosis Membrane | AQUAPHOR ULP3213-1000 × 1 (Series Specification) |
| Sediment Prefilter | 5-Micron Polypropylene Cartridge |
| Carbon Prefilter | 5-Micron Carbon Cartridge |
| Prefilter Housing | 2 × GROSS 10-Inch Housings |
| Feed Pump | Integrated |
| Water Recovery | 50–60% (Manufacturer Series Specification) |
| Mineralisation Adjustment | Adjustable Bypass |
| Bypass Remineralisation | Yes |
| TDS Monitoring | Integrated Inline TDS Meter |
| Control System | Electronic Controller |
| Display | Integrated Digital Screen |
| Prefilter Resource Monitoring | Yes |
| Electrical Power | Manufacturer Series Listing: 0.12 kWh; Rating Requires Confirmation |
| Electrical Voltage | Confirm with Manufacturer |
| Electrical Frequency | Confirm with Manufacturer |
| System Construction | Protective Coated Metal Case |
| Stainless Steel Case | Alternative Version Available |
| Colour / Finish | Dark Coated Metal Enclosure |
| Dimensions (L × W × H) | 42 × 37 × 12.5 cm |
| Product Weight | Pending Manufacturer Verification |
| Installation Type | Compact / Portable Commercial Installation |
| Connection Type | Direct Water Supply Connection |
| Drainage Requirement | Required for Reverse Osmosis Reject Water |
| Regeneration Salt Required | No |
| Cartridge Replacement | Replaceable Prefilters and RO Membrane |
| Maintenance | Periodic Prefilter, Membrane and System Checks |
| Recommended Application | Professional Coffee Machines and HoReCa Water Treatment |
| Manufacturer | AQUAPHOR International OÜ |
| Warranty | Subject to Manufacturer / Supplier Terms |
Water Filtration and Treatment Functions
| Function | Application |
|---|---|
| Reverse Osmosis Purification | Reduces dissolved salts and a broad range of impurities |
| Water Hardness Reduction | Reduces calcium and magnesium concentrations |
| Limescale Prevention | Helps protect boilers, heaters, valves and internal water circuits |
| Sediment Filtration | Removes suspended particles through polypropylene prefiltration |
| Carbon Prefiltration | Reduces chlorine, unwanted taste and odour compounds |
| TDS Reduction | Reduces the dissolved solids concentration of incoming water |
| Mineralisation Adjustment | Adjusts the final treated-water mineral content using a bypass |
| Water Quality Monitoring | Monitors water quality through an inline TDS meter |
| Prefilter Monitoring | Supports planned prefilter maintenance and replacement |
| High-Capacity Water Production | Produces up to 100 litres of purified water per hour |
| Water Recovery Management | Recovers a proportion of inlet water as treated permeate |
| Equipment Protection | Helps reduce scale-related maintenance of connected appliances |
| Beverage Water Preparation | Supports consistent water quality for coffee and hot beverages |
Key Product Features
-
Professional Reverse Osmosis Technology: Advanced membrane separation reduces dissolved salts, water hardness and a wide range of contaminants.
-
100L/Hour Purified Water Capacity: Suitable for professional beverage operations requiring a consistent supply of treated water.
-
AQUAPHOR RO Membrane: High-performance membrane system designed for efficient dissolved-solids reduction.
-
Adjustable Mineralisation Bypass: Allows operators to regulate residual mineral content by blending untreated and purified water.
-
Integrated Inline TDS Monitoring: Provides convenient monitoring of water quality and filtration performance.
-
Smart Electronic Controller: Supports system monitoring and operational control through an integrated digital display.
-
Two-Stage Prefiltration: Polypropylene sediment and activated carbon cartridges help protect the RO membrane from particulate matter and chlorine.
-
Integrated Feed Pump: Supports reliable water supply pressure to the membrane system.
-
50–60% Water Recovery: Manufacturer-published recovery range for the APRO 100 PRO series configuration.
-
Low-Energy Operation: Energy-efficient design intended to reduce operational costs.
-
Compact Portable Construction: Integrates essential RO components into a space-efficient protective enclosure.
-
Plug & Play Configuration: Designed to simplify professional installation and commissioning.
-
High Inlet TDS Tolerance: Suitable for feedwater with TDS concentrations up to 1,500 ppm, subject to other inlet-water requirements.
-
Scale Protection for Coffee Equipment: Helps prevent mineral deposits in boilers, heating systems and water pathways.
-
Consistent Beverage Water Quality: Adjustable mineral content supports repeatable coffee brewing conditions.
-
Replaceable Filtration Components: Serviceable sediment, carbon and RO membrane components support ongoing maintenance.
-
Reduced Dependence on Regeneration Chemicals: Reverse osmosis purification does not require conventional softener regeneration salt.
-
Suitable for HoReCa Environments: Designed for cafés, restaurants, hotels and professional beverage equipment applications.
Included Accessories and Components
| Component | Description |
|---|---|
| Coated Metal Enclosure | Protective compact system housing |
| 2 × GROSS 10-Inch Prefilter Housings | Housings for sediment and carbon prefiltration |
| 5-Micron Sediment Cartridge | Polypropylene prefilter for suspended particles |
| 5-Micron Carbon Cartridge | Carbon prefilter for chlorine, taste and odour reduction |
| AQUAPHOR RO Membrane | Reverse osmosis membrane module |
| Integrated Feed Pump | Supplies pressure for membrane filtration |
| Adjustable Mineralisation Bypass | Allows control of final mineral concentration |
| Electronic Control Panel | System monitoring and operational controls |
| Digital Display | Displays system information |
| Inline TDS Monitoring | Measures dissolved-solids concentration |
| Instruction / Technical Documentation | Operating and maintenance documentation, subject to supply package |
Recommended Applications
Ideal for professional espresso machines, commercial bean-to-cup coffee machines, automatic coffee vending equipment, beverage dispensers, hotel coffee stations, restaurants, cafés, office beverage installations and commercial water treatment applications.
The system is particularly suitable for businesses seeking to improve incoming water quality, reduce scale-related equipment failures, maintain controlled mineral levels for coffee preparation and extend the service life of professional beverage equipment.
